BX-3 2 WD Offroad Chassis Scala 1:5
The BX-3 is a complete new construction developed for competition. Extensive tests during the last weeks confirmed the potential of the new BX-3.
The chassis offers a lot of features and adjustment possibilities without neglecting ease of servicing which is very important especially with Off-road cars.
Features of the BX-3:
- The position of the rc-plate with fuel tank and be changed for better weight allocation
- The motor can be mounted vertically and horizontally
- Very long a-arms as well as large-volume dampers facilitate big spring travel
- Adjustable roll center at the rear axle
and much more…
| Acquista online i prodotti Harm su Modellismo.it oppure consulta l’elenco dei rivenditori. |
Equipment of the H.A.R.M. BX-3
- bended alloy chassis 5 mm
- Carbon fiber reinforcement for the chassis plate
- Alloy bulkheads
- Alloy a-arms front
- Alloy axle hubs front
- Alloy-damper support front
- Damper quick release
- Precision oil damper with large volume
- Alloy servo-plate
- Alloy a-arms rear, lower
- Alloy differential, manual adjustable
- Alloy differential mounts
- Alloy damper plate rear
- Steel ball driving axles
- Alloy axle hub rear
- 3-hole motor mount, self-centering
- 26 cc motor Zenaoh G260 RC
- Servo saver adjustable
- Alloy steering stop
- Rear hub with studs
- Additional support of the main shaft
- hydraulic central brake
- adjustable wing support
The BX-3 is delivered as kit. A detailed instruction is included. On demand the chassis can also be delivered already mounted.
Caratteristiche tecniche del prodotto:
- Lunghezza: 720 mm
- Larghezza: 475 mm
- Interasse: 535 mm
- Peso: 10 - 11,5 kg (circa)
- Zenoah G260 RC
